| MIDI Control | Full assignable MIDI controls |
| DVS Control |
|
| Accessories |
|
| Width | 437.6 mm |
| Depth | 467 mm |
| Height | 107.9 mm |
| Weight | 11.9 kg |
| Sampling Rate | 96 kHz |
| A/D Converter | 32 bit |
| D/A Converter | 32 bit |
| S/N Ratio Line | 105 dB |
| S/N Ratio Phono | 88 dB |
| Frequency Range | 20 - 40000 Hz |
| S/N Ratio Mic | 79 dB |
| Distortion | < 0.005 % (LINE) |
| EQ | 4 band |
| EQ Range | [Hi/Low] -∞ ~ +6 dB / [Hi Mid/Low Mid] -26 dB ~ +6 dB dB |
| Channels | 6 |
| Filter |
|
| SEND |
|
| MULTI I/O |
|
| Beat FX |
|
| Mic Connection |
|
| Talkover | 3 Position Switch |
| Inputs |
|
| Send/Return |
|
| LAN | 1 |
| Outputs |
|
| USB |
|
